Are you in need of the Alukap-SS High Span Wall Bar system?

Experience the ultimate glazing finish with Clear Amber | Alukap®-SS High Span Wall Bar (2-6m). This versatile wall bar features an integral upstand for waterproofing and a sleek structure perfect for unsupported glazing spans up to 6m. Choose from various glazing materials and thicknesses to create a stunning, long-lasting finish for your residential, public, or commercial canopy or roofing structure. Request estimated load span advice or seek independent verification to ensure the perfect fit for your specific site. Revitalize your space with the superior performance and aesthetic appeal of Alukap®-SS.

Dry Verge & Roofline Direct offers the Alukapp SS High Span Wall Bar in a range of lengths from 2m to 6m, as well as colours such as brown, powder coated and white - so you are guaranteed to find the perfect product for your project.

Aluminium High Span Glazing Bars

The revolutionary Alukap®-SS system with world-class design and Patent Pending technology, provides unmatched strength for commercial and residential canopy glazing. Crafted from durable powder-coated aluminium, it is built to withstand the toughest conditions and provide a lasting solution. Seamlessly compatible with various glazing options, such as Axiome® polycarbonate sheet, single glass glazing, and double glazed units, the system comes in classic White RAL 9010 and Brown RAL 8040, allowing for easy color coordination. With an impressive span of up to 6m, the Alukap®-SS High Span Bar is the ultimate choice for all building and canopy projects. Trust Alukap®-SS to deliver exceptional quality and strength for all your glazing needs.

  • Suits any thickness of glass or Axiome sheet

  • Reduces Installation time due to installation friendly design

  • Range of lengths and colours

  • Immense Spanning Capabilities


Product Specifications:

  • Brand: Alukap-SS

  • Sizes Available: 2m, 2.4m, 3m, 3.6m, 4.8m & 6m

  • Colours Available: Brown, Powder Coated & White

  • Life Expectancy: 20 Years


Product Name Product Width (mm) Product Length/Depth (mm) Product Height (mm) Width x length Product Weight (KG)
Alukap-SS High Span Wall Bar 2.0m Brown 58 2000 134 58mm x 2000mm 4.87
Alukap-SS High Span Wall Bar 2.0m PC 58 2000 134 58mm x 2000mm 4.87
Alukap-SS High Span Wall Bar 2.0m White 58 2000 134 58mm x 2000mm 4.87
Alukap-SS High Span Wall Bar 2.4m Brown 58 2400 134 58mm x 2400mm 5.86
Alukap-SS High Span Wall Bar 2.4m PC 58 2400 134 58mm x 2400mm 5.86
Alukap-SS High Span Wall Bar 2.4m White 58 2400 134 58mm x 2400mm 5.86
Alukap-SS High Span Wall Bar 3.0m Brown 58 3000 134 58mm x 3000mm 7.40
Alukap-SS High Span Wall Bar 3.0m PC 58 3000 134 58mm x 3000mm 7.40
Alukap-SS High Span Wall Bar 3.0m White 58 3000 134 58mm x 3000mm 7.40
Alukap-SS High Span Wall Bar 3.6m Brown 58 3600 134 58mm x 3600mm 8.88
Alukap-SS High Span Wall Bar 3.6m PC 58 3600 134 58mm x 3600mm 8.88
Alukap-SS High Span Wall Bar 3.6m White 58 3600 134 58mm x 3600mm 8.88
Alukap-SS High Span Wall Bar 4.8m Brown 58 4800 134 58mm x 4800mm 11.72
Alukap-SS High Span Wall Bar 4.8m PC 58 4800 134 58mm x 4800mm 11.72
Alukap-SS High Span Wall Bar 4.8m White 58 4800 134 58mm x 4800mm 11.72
Alukap-SS High Span Wall Bar 6.0m Brown 58 6000 134 58mm x 6000mm 14.60
Alukap-SS High Span Wall Bar 6.0m PC 58 6000 134 58mm x 6000mm 14.60
Alukap-SS High Span Wall Bar 6.0m White 58 6000 134 58mm x 6000mm 14.60

Data Sheet & Fitting Instructions:

Common uses

  • Commercial Canopies
  • Covered Decking Areas
  • Carports
  • Orangeries & Conservatories
  • Rooflights
